MOUNTING OPTIONS
SQUARE ARMS WITH TENON
• TENON: 2” STEEL PIPE SCH. #40 (2-3/8” O.D. x 4” LONG)
• ARM: 3” xq. X 120” WALL STEEL TUBE.
• MOUNTING PLATE: 3/16” THICK STEEL (SPECIFY PLATE DIMENSION, SIZE AND PATTERN OF MOUNTING HOLES.
• SLIP FITTER: 3” SQ. x 120” WALL x 10” LONG, STEEL TUBE WITH REMOVABLE CAP AND (3) 3/8-16 SET SCREWS.
• FINISH: “P”-PRIME; “BK”-BLACK; “BZ”- BRONZE (“G”-GALVANIZED) |  | BULLHORN ARMS
• ARM: 2” STEEL PIPE Sch. #40 (2-3/8” O.D.)
• SLIPFITTER: STEEL PIPE FOR 2-3/8” O.D. OR 2-7/8” O.D.- TENON (SPECIFY)- COMPLETE ASSEMBLY SHALL INCLUDE REMOVABLE CAP AND (3) 3/8-16 SET SCREWS.
• FINISH: “P”-PRIME; “BK”-BLACK; “BZ”- BRONZE (“G”-GALVANIZED) |  |
STEEL POLE OPTIONS
STRAIGHT STEEL SQUARE POLE |  | MODEL | WALL | SHAFT SIZE | HT. | BASE PLATE | BOLT CIRCLE | FINISH | ANCHOR BOLTS | D | E | SSS-11-416 | .120” | 4” SQ | 16’ | 9 1/2” | 1/2” | 9 1/2” | BZ | 3/4 x 16 x 3 | SSS-11-420 | .120” | 4” SQ | 20’ | 9 1/2” | 3/4” | 9 1/2” | BZ | 3/4 x 24 x 3 | SSS-7-420 | .180” | 4” SQ | 20’ | 9 1/2” | 3/4” | 9 1/2” | BZ | 3/4 x 24 x 3 | SSS-11-425 | .120” | 4” SQ | 25 | 9 1/2” | 3/4” | 9 1/2” | BZ | 3/4 x 24 x 3 | SSS-7-425 | .180” | 4” SQ | 25 | 9 1/2” | 3/4” | 9 1/2” | BZ | 3/4 x 24 x 3 | SSS-11-525 | .120” | 5” SQ | 25 | 11 3/4” | 3/4” | 12” | BZ | 3/4 x 24 x 3 | SSS-7-525 | .180” | 5” SQ | 25 | 11 3/4” | 3/4” | 12” | BZ | 1 x 36 x 4 | SSS-11-530 | .120” | 5” SQ | 30’ | 11 3/4” | 3/4” | 12” | BZ | 1 x 36 x 4 | SSS-7-530 | .180” | 5” SQ | 30’ | 11 3/4” | 3/4” | 12” | BZ | 1 x 36 x 4 |
