PACIFIC LIGHTING & STANDARDS CO
Traditional | Decorative | Contemporary | Architectural | Low Pressure Sodium | Wall and Ceilings | Bollards | Poles | Base Covers | Arms


Downloads
Specification Sheet

ST

Product Details
Housing   1/8”  thick spun aluminum hood with (4) 1” O.D. extruded aluminum supports and cast aluminum pole fitter.
Lens   Injection molded polycarbonate cylinder.
Electrical   All electrical components are UL approved.
Ballast   High power factor - 20°C starting temperature. The ballast is removable as a unit for easy maintenance.
Reflector   Spun aluminum white painted.
Arms   Extruded and/or cast aluminum.
LED Engine   All LED light boards and drivers are separate and removable for easy maintenance and replacement
Finish   Polyester powder fuse coating is standard; other finishes are available upon request.

Ordering Information
1. Model Number
2. Wattage
3. Lamp Type
     H - Metal Halide
     S - High Pressure Sodium
     PS - Pulse Start
     CF - Compact Fluorescent*
     LED - Light-emitting diode
     IND - Induction
4. Voltage
     120, 208, 240, 277, 480 and
     MT (Multi Tap) - 120, 208, 240, 277
5. Mounting Style
     & Arm Style
6. Finish
     BK - Black
     BZ - Bronze
     GR - Green
     VG - Verde Green
     ( Other color upon request)
7. Options
     FS - Fuse
     PC - Photo Cell

Variant Options
